SAMSUNG The Wall All-in-One Digital Signage, 146″ 4K UHD Display,(LH008IABMUS/UE)

SAMSUNG The Wall All-in-One Digital Signage

SAMSUNG The Wall All-in-One Digital Signage, 146″ 4K UHD Display, 0.84mm Pixel Pitch, 1600 nit Peak Brightness, HDR10/10+, Dynamic Peaking, SmartView+, Dicom Simulation Mode, Black | LH008IABMUSPower on an awe-inspiring viewing experience with The Wall All-in-One. Engineered to be quickly enjoyed out of the box, Samsung’s most advanced and stunning display makes a bold statement in any environment. With the Wall All-in-One you simply choose your size and resolution, and you’re assured of a complete, easy-to-install, brilliant solution. Choose from three pre-configured sizes: 110” 2K, 146” 2K or 146” 4K.

• Physical Parameters

  • Pixel Pitch: 0.84 mm

  • Pixel Configuration: 1 red, 1 green, 1 blue

  • Diode Type: Flip-chip RGB LED

  • Configuration (L × H): 3840 × 2160 pixels (per screen)

  • Dimensions (L × H × D): 127.1 × 71.6 × 1.9 inches (per screen)

  • Dimensions (Length × Depth): 145.7 × 1.9 inches

  • Number of Modules (W × H): 16 × 12 (per screen)

  • Weight: 352.7 lbs (per screen)

  • Size: 146″ UHD

  • General Feature: IA Series

• Optical Parameters

  • Brightness (Peak/Max): 1600 nit / 500 nit

  • Contrast Ratio: 24,000:1

  • HDR Compatibility: LED HDR, HDR10+, AI Picture

  • Viewing Angle – Horizontal: 170°

  • Viewing Angle – Vertical: 155°

  • Bit Depth: 16 bit (Internal processing: 20 bit)

  • Color Temperature (Default): 6,500K ± 500K

  • Color Temperature (Adjustable): 2,800K ~ 10,000K

• Electrical Parameters

  • Video Rate: 50/60 Hz, 100/120 (FRC) Hz

  • Input Power Range: 100~240 VAC, 50/60 Hz

  • Power Consumption (Max): 1240 W (per screen)

  • Power Consumption (Typical): 860 W (per screen)

  • Heat Generation (Typical): 3753 BTU (per screen)

  • Refresh Rate: 3840 Hz

  • Heat Generation (Max): 5800 BTU (per screen)

• Operation Conditions

  • Working Temperature/Humidity: 32°F ~ 104°F / 10% ~ 80% RH

  • Storage Temperature/Humidity: -4°F ~ 113°F / 5% ~ 95% RH

  • IP Rating: IP20

  • LED Lifetime: 150,000 hours

• Package

  • Box Dimensions: 78.7 × 85.11 × 39.4 inches

  • Package Weight: 533 lbs

• Certification

  • Eye Protection: TUV Low Blue Light

• Service

  • Service Type: Front

• Features

  • Operating System: Tizen 6.5

  • MagicINFO: Yes

  • Sensors: Temperature, Eco Sensor

  • Other Features: AI Picture, LED HDR, HDR10/10+, Dynamic Peaking, SmartView+, Dicom Simulation Mode

  • Software Features: Workspace (Microsoft 365 / VMWare / RDP), Auto Source Switching & Recovery

• Connectivity / Sound

  • Controller: Built-in

  • Video Inputs: DP 1.2 (1), HDMI 2.0 (3), USB 2.0 (2)

  • Outputs: Audio (Stereo Mini Jack), eARC

  • WiFi / Bluetooth: Yes / Yes

  • External Control: RS232C (in), RJ45

  • Speaker: 10W 2CH

• Accessories

  • Included Accessories: Décor Frame, Frame Kit, Buffer Parts (18 Modules, 1 T-Con, 1 SMPS)

  • Remote Control: IR Remote Controller

• Special Installation

  • Installation Options: Side-by-Side with Additional Frame Kit (up to 4 screens)

• Certification / Compliance

  • Safety: 62368-1, 60950-1

  • EMC: Class A
