Specification

Processor

• Model: AMD Ryzen™ 5 8400F
• Family: AMD Ryzen™
• Series: Ryzen™ 8000 Series
• Architecture: Zen 4
• Former Codename: Phoenix
• Platform: Desktop

Performance

• CPU Cores: 6
• Threads: 12
• Base Clock: 4.2 GHz
• Max Boost Clock: Up to 4.7 GHz
• L2 Cache: 6 MB
• L3 Cache: 16 MB
• Default TDP: 65W
• Configurable TDP: 45W–65W

Manufacturing Technology

• CPU Process: TSMC 4nm FinFET
• CCD Size: 178 mm²
• Package Die Count: 1

Platform & Overclocking

• Socket: AM5
• Supported Chipsets: A620, B650, B650E, B840, B850, X670, X670E, X870, X870E
• Unlocked for Overclocking: Yes
• AMD EXPO™ Memory Overclocking: Yes
• Precision Boost Overdrive: Yes
• Curve Optimizer: Yes
• AMD Ryzen™ Master Support: Yes
• CPU Boost Technology: Precision Boost 2

Memory Support

• Memory Type: DDR5 UDIMM
• Memory Channels: 2
• Maximum Memory Capacity: 256 GB
• Memory Speed Support:
  • 2x1R: DDR5-5200
  • 2x2R: DDR5-5200
  • 4x1R: DDR5-3600
  • 4x2R: DDR5-3600

Connectivity & Expansion

• PCIe Version: PCIe® 4.0
• Native PCIe Lanes (Total / Usable): 20 / 16
• USB 4 (40Gbps): 2
• USB 3.2 Gen 2 (10Gbps): 2
• USB 2.0: 1
• NVMe Support: Boot, RAID 0, RAID 1

Graphics & AI

• Graphics: Discrete Graphics Card Required
• AMD SmartAccess Memory: Available
• AMD Ryzen™ AI: Not Available

Thermal & Operating Conditions

• Maximum Operating Temperature (Tjmax): 95°C

Operating System Support

• Windows 11 (64-bit)
• Windows 10 (64-bit)
• Ubuntu x86 64-bit
• RHEL x86 64-bit

Security Features

• AMD Enhanced Virus Protection (NX Bit): Supported

Supported Technologies

• AMD EXPO™ Technology
• AMD Ryzen™ Master
• AMD SmartAccess Memory
• AMD Ryzen™ Technologies
