5X ZOOM

Perfectly frame presenters to minimize background distractions. Zoom in on whiteboards and objects so remote participants can see what you see. Thanks to its advanced 4K image sensor, video remains sharp and clear, even when you zoom in on the details.

PREMIUM CAMERA OPTICS

MeetUp features exquisitely engineered, premium camera optics that capture a wide field-of-view without distorting faces and furniture with a “fisheye” effect. Faces look natural, whiteboard writing remains legible, and straight lines stay straight.

EXTENDED RANGE

Logitech Expansion Mic for MeetUp provides greater flexibility in huddle room configurations. MeetUp’s built-in beamforming mics are optimized for up to 4 meters. To extend that range up to 5 meters, add an Expansion Mic. So whether people are seated at a table, sitting against the wall, or walking around the room, Expansion Mic for MeetUp means everyone will be heard.

TAKE CONTROL

When you need to adjust the volume, mute the microphone, or take manual control over camera position, MeetUp’ s remote control uses radio frequency (RF) signals for reliable and discreet control from anywhere in the room. You can even download the free Logi Remote app (available on iTunes) to control MeetUp with an iPhone or iPad.

WALL SAVER

No drilling? No problem. By attaching to the VESA mounting points behind the display, the optional TV Mount for MeetUp lets you position MeetUp above or below the display without drilling new holes.

RIGHTSENSE TECHNOLOGIES

Logitech RightSense™ proactive technologies make better video meetings easy and automatic. RightSound optimizes the human voice and enhances conversational clarity, RightSight automatically moves the camera and adjusts the zoom so no one gets left out of the picture, and RightLight helps everyone look their best on camera, regardless of lighting conditions.

Specification

Dimensions

Main Unit

• Height: 104 mm
• Width: 400 mm
• Depth: 85 mm
• Weight: 1.04 kg

Remote Control

• Height: 83 mm
• Width: 83 mm
• Depth: 10 mm

Technical Specifications

Camera

• Custom Logitech lens
• 5× HD Zoom
• Motorized Pan/Tilt:
  • Pan: ±25°
  • Tilt: ±15°
• Field of View (FOV):
  • Diagonal: 120°
  • Horizontal: 113°
  • Vertical: 80.7°
• Total Room Coverage:
  • 163° Wide × 110° Tall
• 3 programmable camera position presets
• RightSight Auto-Framing
  • Requires Windows 10 (64-bit) or macOS 10.14+

Video Performance

• 4K Ultra HD Video
  • Up to 3840 × 2160 @ 30 fps
  • Requires USB 3.0 cable and port
• 1080p Full HD Video
  • Up to 1920 × 1080 @ 30 fps
• 720p HD Video
  • Up to 1280 × 720 @ 30 fps

Microphone

• Integrated microphone array with 3 beamforming elements
• Pickup Range:
  • MeetUp: 4 m
  • With Expansion Mic: 5 m
• Sensitivity: -27 dB
• Frequency Response: 90 Hz – 16 kHz
• Sampling Rate: 32 kHz
• Factory-paired beamforming algorithm for:
  • Enhanced voice pickup
  • Noise reduction
  • Low distortion
• Acoustic Echo Cancellation (AEC)
• Voice Activity Detection (VAD)

Recommended Room Capacity

• Up to 6 participants (built-in microphones)
• Up to 8 participants (with expansion microphone)

Speaker

• Maximum Volume: 95 dB SPL at 0.5 m (peak)
• Sensitivity: 86.5 ± 3 dB SPL at 0.5 m
• Distortion:
  • 200–300 Hz: < 3%
  • 3 kHz–10 kHz: < 1%
• Patent-pending anti-vibration enclosure:
  • Improves voice clarity
  • Minimizes sound transmission to adjacent rooms

General Features

• Bluetooth wireless technology
• RF remote control
• Integrated table and wall mount
• Optional TV mount available
• Kensington security slot

RightSense Technologies

RightLight

• Low-light compensation
• Video noise reduction
• Low-light saturation optimization

RightSight

• Human figure detection
• Automatic participant framing at meeting start
• On-demand auto-framing
• Dynamic reframing when participants:
  • Enter the room
  • Leave the room
  • Change positions

RightSound

• Acoustic Echo Cancellation (AEC)
• Voice Activity Detection (VAD)
• Automatic voice-level adjustment
• Peak-limiting algorithm to prevent clipping and distortion
• Anti-vibration speaker enclosure

Operating System Requirements

Supported Operating Systems

• Windows 10
• Windows 11 or later
• macOS (two most recent versions)
• Chrome OS Version 29.0.1547.70 or later

Connectivity Requirements

• USB 2.0 port
• USB 3.0 port and cable required for 4K video operation

Certifications and Compatibility

• Compatible with major video conferencing platforms
• Certification and compatibility information available through Logitech’s video collaboration certification program

Package Contents

Included Components

• MeetUp ConferenceCam
• RF Remote Control
• USB 2.0 Cable (5 m)
• Power Supply
• Wall Mount and Mounting Hardware
• User Documentation
